Replace 40 watt T8 or T12 fluorescent lamps with 50,000hr G13 base T8 LED lamp for easy installation in ballast bypass retrofit applications where power is supplied through both ends of the tube and shunted sockets / tombstones are installed.
- Suitable for damp locations
- Not for use with dimmers
- Not intended for emergency exits
- Do not exceed an operating temperature of 113° F
-
How much brighter are the LED T8 retrofit tubes then my existing fluorescent T8 tubes?
Putting the issue on how many lumens aside for now, we thought we would do a real world test. Here is what we did. We put up just one fluorescent T8 32watt tube at 3000K in our fixture and at 4' from the fixture we measured 31 foot candles. We did the same test with the 4000K LED-T8 18 watts and got a reading of 61 foot candles and with the 5000K LED-T8 20watts we got a reading of 64 foot candles. Now it is important to remember that the human eye will see the light a little different. The 5000K will give a very cool-white color that may be good for some installations. The 4000K will be a little warmer in color, and although it may not appear to be as bright, it may make the environment more pleasing. The light output on both LED tubes measures almost double to that of fluorescent tubes.
| Warranty | Manufacture's 5 Year Limited |
|---|---|
| Important Note | We always recommend a licensed electrician for all electrical projects. Do not use dimmers on this lamp. |
| Bulb Wattage | 18 |
| Input Voltage | 120-277VAC |
| Voltage Type | Line Voltage |
| Bulb Base | G13 |
| Bulb Type | T8 |
| Bulb Length | 4ft. |
| Application | Replace T8 and T12 fluorescent lamps, General lighting, energy saving lighting |
| Average Hours | 50,000 |
| Cross Reference Number | L4-T8F-18WFS1-4000K |
| Dimmable | No |
| Material | Glass |
| Approvals | cULus, DLC, FCC |
| Bulb Emit Color | Natural White |
| Lumens | 2200 |
| Color Temperature ( K ) | 4000 |
| Color Render Index (CRI) | 80 |
| Incandescent Equivalent Wattage | 40 |
| Diameter (in) | 1.18" |
| Max Overall Length (MOL) | 47.76" |
-
